The Raptor XD is the ideal zero-turn for homeowners with up to five acres of property. Powered by a strong 23hp Kawasaki engine and paired with a tough 54 inch fabricated cutting deck, it delivers durability, performance, and consistently clean cut quality.
Meet the Hustler XD 54, the ultimate solution for your lawn care needs. Equipped with a powerful 23HP Kawasaki V-Twin engine, this mower is designed to make mowing large areas efficient and effortless.
Take a seat on the comfortable high-back seat with padded armrests and mow for extended periods without fatigue. The foot-operated deck lift system allows you to easily adjust the cutting height while remaining seated, making it simple to adapt to changing terrain and grass conditions.
With its zero turn radius, the XD 54 offers exceptional manoeuvrability, allowing you to navigate around obstacles and turn in tight spaces with ease, making it ideal for both residential and small commercial properties.
The intuitive control panel keeps all essential functions within reach so you can focus on completing the job quickly and efficiently.
Built with a sturdy steel frame and a durable 54 inch fabricated cutting deck, the Hustler XD 54 is designed for long-term reliability. A removable foot pan provides easy access to belts and pulleys, simplifying routine maintenance.
Experience the difference of the Hustler XD 54 zero turn mower and enjoy a more comfortable and effortless lawn care experience.
Cutting Equipment & Features
Deck Width & Construction54 Inch 11 Gauge Fabricated Cutting Deck
Blades & PTO3 Blades with electric PTO blade engagement
SpindlesAluminum with 7 gauge spindle mounts, 1” shaft and double lip sealed ball bearings
Cutting Height & Adjustment1.5" - 4.5" cutting range with foot assisted deck height adjustment
Acres per hour3.2 Acres per hour (Rating based on 80% efficiency to allow for real world mowing conditions)
Fuel Tank Capacity11 L
Slope Capability15 Degrees
Power & Drive Train
Engine Type & Specifications23HP Kawasaki FR691V Engine. Air cooled. 726cc.
Engine Warranty3 Year Engine Warranty
Transmission Type & SpecificationsDual Hydro Gear ZT2800 Hydro Transmissions
Build & Chassis
Country of ManufactureMade in the USA
Chassis Construction1.5" x 3" Welded Tubular Steel Frame
Rear Wheels & Tyres20" x 8" Rear Tyres
Front Wheels, Tyres & Castors13" x 6.5" Front Tyres
Comfort & Convenience
Seat TypeBolstered High Back Seat with Armrests
Console FeaturesCup Holder
Park BrakeAutomatic Park Brake
SuspensionOptional Flex Fork Front Suspension
Maintenance AccessOpen rear design for easy engine maintenance
Tow HitchOptional Tow Hitch
Dimensions
Minimum Trailer Size5 ft wide, 7 ft Long
Length1806 mm
Width (Chute up)1486 mm (Chute up)
Height (ROPS up & down)1110 mm
Weight296 kg
Warranty
Residential Warranty3 Year / 300 Hr Domestic warranty
Commercial Warranty3 Year / 300 Hr Commercial warranty
* Images shown may sometimes be from comparable models supplied by the manufacturer. Availability can change frequently, so we recommend contacting us to confirm current stock.
