Gravely Compact Pro 34" Zero-Turn Mower

The Gravely Compact Pro 34" delivers full commercial strength in a compact frame, built to access tight spaces while maintaining powerful performance and durability.

Key Features
  • 15.5 hp Kawasaki FX481V Engine
  • Hydro Gear ZT-3100 Dual Hydrostatic Transmission
  • 10-Gauge Fabricated Deck with Reinforcement
  • 17 Cutting Positions (25 mm - 127 mm)
  • Fully Welded Tubular Frame
  • 2.4 Acres Per Hour Productivity
Small frame. BIG results. The Gravely Compact Pro 34 Zero-Turn Mower delivers full commercial performance in a compact design capable of fitting through gates as narrow as 36 inches. Powered by a 15.5 hp Kawasaki FX481V engine with a heavy-duty remote canister air filtration system, this mower is built to perform in demanding conditions while extending engine life. The Hydro Gear ZT-3100 dual hydrostatic transmission provides smooth, responsive drive control and increased durability. The 10-gauge fabricated deck with 10-gauge spindle reinforcement and forged aluminium cutter spindles ensures long-term reliability and professional cut quality. With 17 cutting positions ranging from 25 mm to 127 mm, you can achieve a precise finish across varied terrain. A fully welded 1" x 3" steel tubular frame delivers superior strength, while seat isolation and EVC suspension help absorb rough terrain and reduce operator fatigue. The 27.1 litre fuel tank supports extended run time for larger jobs. Designed for commercial users who need access to confined spaces without compromising on power or build quality, the Gravely Compact Pro 34 offers exceptional versatility, productivity and durability.
Warranty Information
Domestic Warranty4 Year / 750 Hour Domestic Warranty
Commercial Warranty4 Year / 750 Hour Commercial Warranty
Miscellaneous
Blade(s)2 x Bar blades
Dimension Specs
Dry Weight334.3 kg
Height1155 mm
Width911.8 mm With chute up
Length75" (1905 mm)
Zero Turn Mower Specs
Ground Speed - ForwardUp to 11.2 km/h
BrakesHand brake
SeatHigh back with EVC suspension
ConstructionFrame 1" x 3" STEEL Tubular frame welded
ROPSROPS not supplied with unit
ControlsHand-operated choke, throttle, ignition switch, electric mower clutch, Hand Park brakes
Cup HolderYes
Deck LiftFoot-operated
Deck ConstructionFabricated 10 Gauge w' 10 Gauge spindle reinforcement
Blade Tip Speed17250 FPM
Blade DriveV-belt drive to spindles with electric clutch. Spring tension idler pulleys for extended belt life
SpindlesForged Aluminium with sealed ball bearings
Drive SystemV-belt drive from engine crankshaft
Discharge ChuteHigh density, rubberised
SteeringTwin-lever steering provides independent control of each drive wheel
Engine and Fuel Specs
EngineKawasaki FX481V
Engine (cc)603 cc
Horsepower15.5 hp
CoolingAir cooled flywheel fan
FuelUnleaded fuel - maximum of 10% ethanol
Fuel FilterReplaceable, automotive-type
Oil FilterSpin-on engine oil filter / Total oil capacity 1.7 litres with filter
Air FilterMulti-Stage remote canister heavy duty air filter system
Fuel Capacity27.1 L
GovernorMechanical
Safety Features
Safety FeaturesOperator presence system connected to clutch, seat, and park brakes
Hydrostatic Drive System Specs
Hydrostatic Drive SystemDual hydrostatic
Drive CoolingTransmission mounted fans
PumpsHydro Gear ZT-3100
Cutting Dimensions
Cutting Widths34" (863 mm) cut side discharge.
Cutting Height(s)25 mm - 127 mm

* Images shown may sometimes be from comparable models supplied by the manufacturer. Availability can change frequently, so we recommend contacting us to confirm current stock.
